Electronic Message Centers (EMC's) - outdoor LED signs - became more and more popularity in recent years, this LED signages are great tools for increasing visibility,
It features with energy-efficient brilliance, user-friendly content management, it play the live time and temperature as well as utilize animation, color usage and graphic elements to create a visual impact to grab the viewer's attention.
It provide quick and effective communication that is essential for every business or organization — whether you run a shop, gas station, church, school, restaurant or even a bank, EMCs provide versatile and effective communication solutions.
Most importantly, it's very durable and low maintenance, size and shape are flexible to customize.
| Pixel pitch(mm) | P2.976 | P3.91 | P4.81 | P5.33 | P6.67 | P8 | P10 | P10 | P16 | P20 |
| Pixel Density (dots/sqm) | 112,896 | 65,536 | 43,264 | 35,156 | 22,500 | 15,625 | 10,000 | 10,000 | 3,906 | 2,500 |
| Lamps | SMD1921 | SMD2727 | DIP346 | |||||||
| LEDs | NationStar | NationStar | Fortune | |||||||
| Moduel Size | 250mm*250mm | 320mm*320mm | ||||||||
| Cabinet Size | 500mm*1000mm, other size customizable | 960mm*960mm, other size customizable | ||||||||
| Brightness(nits) | 5,500 | 5,500 | 5,500 | 6,000 | 60,000 | 6,000 | 6,500 | 7,500 | 8,000 | 7,500 |
| Max power (W/sqm) | 900 | 900 | 900 | 900 | 900 | 900 | 1,000 | 800 | 600 | 600 |
| Ave power(W/sqm) | 300 | 300 | 300 | 300 | 300 | 300 | 350 | 270 | 200 | 200 |
| Scanning | 1/21 | 1/8 | 1/7 | 1/6 | 1/6 | 1/4 | 1/2 | 1/4 | static | static |
| Min Viewing Distance | 2.5m | 3.5m | 4.5m | 5m | 6.5m | 8m | 10m | 10m | 16m | 20m |
| Viewing Angle | H: 140°. V: 140°. | H: 110°. V: 70°. | ||||||||
| Power supply | MeanWell LRS series | |||||||||
| Input Voltage | AC 80-135v/ 190-265v | |||||||||
| Refresh Frequency | 1920 Hertz | |||||||||
| Brightness Control | 256 level | |||||||||
| Gray Level | ≧14bits | |||||||||
| Blind Spot Rate | ＜1/10000 | |||||||||
| Lifetime | 100,000 hours | |||||||||
| Ingress Protection | IP65 | |||||||||
| Operating Temp | ﹣30～﹢50℃ | |||||||||
| Operating Humidity | 10％～90％ | |||||||||
| Operating System | Windows (11/10/8/7/2000/XP/Vista) | |||||||||
